GPS receiver module with intregrated GPS patch antenna

GPS receiver module characteristics

This GPS receiver module has been designed to address applications where placement flexibility is very important along with stand alone operation, high level of integration and low power consumption. This series are the smallest, autonomous, fully featured GPS receivers, optimised for standalone operation. The GPS modules are complete SiP (System-in-Package) featuring advanced miniature packaging technology and an ultra small footprint designed to commit unique integration features for high volume, low cost and low power applications.   This GPS receiver module has SiRF Star III inside and can provide you superior sensitivity and performance even in urban canyon and dense foliage environment. The GPS antenna patch can be placed somewhere in the enclosure. Last but not least the patch antenna can be replaced to coaxial cable Hirose W.FL to SMA/M bulkhead. GPS module 17x17 is pin compatible to GPS module 18x18.

This GPS receiver module offers the advantages as below

• Dimensions (mm): 17 x 17 x 2.2 (GPS module without GPS patch antenna)
• Coaxial connector W.FL
• SiRF Star III GSC3LT(f)
• 20 parallel channels
• UART and SPI communication
• Fast TTFF at low signal level
• Capable of SBAS (WAAS, EGNOS, MSAS)
• Integrated 18.4 mm x 18.4 mm GPS patch antenna
• Built-in LNA and SAW filter optimised against GSM bursts
• Wide input voltage 3,25 - 5.5 V
• Low power consumption: Tracking 75 mW only including active GPS antenna
• SMD type with stamp hole

Ultra small size designed for tiny applications

Tracking (people, animals, assets), container tracking, vehicle tracking, PDA, POS terminal, Personal positioning and navigation, automotive navigation, marine navigation

Block diagram of GPS receiver module with integrated GPS patch antenna

Based on the embedded SAW filters you get a high protection against the GSM bursts. The GPS module will not interfere with the 2 Watt power level of GSM.

GPS receiver module features

• Frequency L1 1575.42 MHz, C/A code
• Channels 20
• Update rate 1 Hz
• Sensitivity
• Acquisition -157 dBm (Deep Indoor)
• Tracking -159 dBm (Deep Indoor)
• Cold Start -142 dBm
• Acquisition Time
• Hot Start < 1s -130 dBm (Outdoor)
• Warm Start < 35s -130 dBm (Outdoor)
• Cold Start < 40s -130 dBm (Outdoor)
• Signal Reacquisition < 1s -130 dBm (Outdoor)
• Position Accuracy
• (2D RMS) < 5 m -130 dBm (Outdoor)
• (2D RMS) <4 m -130 dBm (Outdoor), SBAS
• Max. Altitude < 60,000 ft
• Max. Velocity < 1,000 knots
• Protocol Support
• NMEA 0183 ver 3.0 9600 bps, 8 data bits, no parity, 1 stop bits (default) 1Hz: GGA, GLL, GSA, GSV, RMC, VTG
• SiRF Binary 38400 bps, 8 data bits, no parity, 1 stop bits
• Power Consumption
• Acquisition 100 mW
• Tracking 75 mW
• Hibernate 100 μW
• Industrial operating temperature range: -40^o to 85^o C

Interfaces

• Power supply nominal 3.3 Volt, wide range  3.25 - 5.5 Volt
• One RS232 on CMOS 1.8V/2.5V/3.3V compatible without flow control (RX, TX)
• SPI bus 1.8 Volt (SDI, SDO, nSE, SCK)
• 50 Ohm antenna
• Backup battery

GPS receiver module dimensions
